| Features | - Capacity: 1/4 Ton
- Headroom: 17.3 in.
- Approximate Weight: 71 lbs.
- Standard Voltage: 115/230-1-60
- Control Voltage: 24DC
- Duty Cycle: 30/10 Min.
- Classification: ASME H4 / ISO 1/8-1/2T M6; 1T M5 / FEM 1/8-1/2T 3m; 1T 2m
- Hoist Rating: IP55
- Pendant Rating: IP65
- Forged carbon steel hooks.
- Low-profile upper and lower limit switches.
- Grade 80 nickel-plated chain is heat treated to increase strength and decrease wear.
- Unique Load Sheave - 5 deep-groove pockets reduce chain vibration during operation.
- Variable Frequency Drive (VFD) - Includes count hour meter, load limiter, and no-load high-speed function.
- Precision Machined Helical Gears - Oil bath lubrication results in quiet, smooth, and cool operation.
- Pull-Rotor Motor Brake - Advanced design with no brake coil to fail like conventional disc brakes.
- External Motor Fan - Improves hoist duty and brake life by quickly eliminating resistor, motor, and brake heat.
- Die-Cast Aluminum Body - Lightweight body with low headroom. Electrostatically applied paint is sealed for indoor and outdoor use.
- Extreme Duty Motor - 30/10-minute Duty Rating, H4 Classification, Class B Insulation, Cooling Fins, and External Thermal Protection.
|
