| Features | - Capacity: 1/2 Ton
- Headroom: 14.6 in.
- Approximate Weight: 71 lbs. / 79 lbs.
- Standard Voltage: 208-230 / 460-3-60
- Control Voltage: 110V
- Duty Cycle: Single Speed - 60 Min. / Dual Speed - 30/10 Min. with VFD
- Classification: ASME H4, ISO M5 or M4, FEM 2M or 1Am
- Hoist Rating: Completely sealed body, IP55
- Pendant Rating: IP65
- 60 minute, H4 rated motor for the most demanding applications.
- All standard models are UL listed to UL 1340 "Standard for Hoists".
- Plug in pendant and power supply cords save time on set up and maintenance.
- Super strength, nickel-plated load chain is corrosion and wear-resistant.
- 5 or 6 pocket load sheave improves chain life and promotes smooth lifting.
- Contactors are mechanically interlocked, heavy-duty contactors on single-speed models.
- Hoist suspension is easily changed from hook to lug mount configurations with external suspension pins on most models.
- Notched Hook and Latch System - provides positive closing and improves resistance against lateral forces standard on most models.
- Smart Brake Technology - revolutionary DC current motor brake with electrical failsafe design.
- Extended Chain Life - decreased chain wear as a result of a revolutionary heat treatment process, improved material, and chain size.
- Easy Access Suspension - external pins allow for quick change from hook to lug for trolley mount configurations on most models.
- Limit Switches - low-profile upper and lower limit switches are standard.
- Friction Clutch and Load Brake - friction clutch is standard on NER/ER models and friction clutch with mechanical load brake standard on ER models. Carbon friction material provides consistent performance over a wide temperature range.
- High Air Flow - cooler motor and brake attributed to an engineered motor fin, fan blade, and fan cover design.
- Heat Treated Helical and Spur Gears - Precision machined for long life. Oil bath lubrication results in a quiet, smooth, cool operation.
- Compact Aluminum Body - Die-cast body is lightweight and offers low headroom – one of the best in the industry. Paint is electrostatically applied.
- Operating Conditions: Recommended for -4° to +104° F and humidity of 85% or less.
|
