| Features | - Capacity: 3-ton / 2,721 kg
- Duty Cycle: Hoist Motor - 30 minutes
- Hoist Housing: Cast lightweight aluminum housing
- Hoist Housing Paint / Finish: Acid-Resistant Powder Coat Paint, CM Orange Color
- Hoist Gear Box: Precision machined helical gearing, is lifetime lubricated with non-oxidizing grease. Precision machined and hardened 5 pocket lift-wheel with hardened chain guides provide smooth operation and long life.
- Load Chain: CM Hoistaloy, Zinc Plated
- Controls: Rugged NEMA 4X push button station. Control voltage of 115 VAC.
- Hoist Brake: Heavy Duty DC Brake
- Hoist Hooks: Hardened, forged steel, safety latch type hooks, powder-coated
- Hoist Classification: ASME H4 (High volume handling of heavy loads, frequently near rated loads, with a total running time not over 50% of the work period.)
- Hoist Standards: Meets ASME B30.16
- H4 Duty is ideal for heavy-duty industrial applications.
- Hoist and trolley furnished with acid-resistant powder coat paint, plated load chain and painted hooks as standard. Contact TSOC for harsh acid environment applications.
- Gearing designed for exceptionally long life and quiet operation. Gear train lifetime lubricated with non-oxidizing grease.
- Hoist duty motor, standard overload protection device and standard screw-type limit switches.
- Hardened, forged-steel, latch-type hooks and Hoistaloy load chain for long, dependable service.
- Precision machined and hardened liftwheel with hardened chain guides to ensure chain fits tightly and securely in liftwheel.
- Voltage board allows you to quickly change from low voltage to high voltage by simply repositioning the receptacle.
- Easy to install and maintain with no special tools required for disassembly.
- Each hoist is thoroughly inspected and tested to over 125% of rated load prior to shipment.
|
